Uniply Fire Protect Plywood is a Combo of Fire Retartdant Plywood with Marine Grade. Uniply’s Unique formulations and manufacturing process has made it possible to make the Fire Retartdant Plywood with Marine Grade properties superior than specified values of BIS IS 5509. Fire retardant characteristic is a very important property to prevent propagation of fire at the initial stages of FIRE and is recommended to be used in ship building, railway coach construction and High rise buildings. Uniply FIRE PROTECT has also passed the American Standards ASTM E84 - 16 (Steiner Tunnel test). So relax & enjoy your life, and leave the worries to Uniply FIRE PROTECT Plywood, Your life is in SAFE HANDS Technical Specifications

Properties - Specified IS 5509:2000

Special Certification - Passes American standard ASTM E84-16

Flammability - >40 mints

Flame Penetration - >24 mints for every 6mm thickness

Rate of Burning - time taken for wt.loss 30% to 70% is >55 mints

Adhesive for Bonding E1 Grade Un - extended BWP Synthetic Resin as per Global Standards

Special Raw Material Treatment - Ammonium phosphates / Ammonium. sulphates/Boron Compounds / TricresylPhosphates

Preservative Treatment - As per IS 5539

Glue Shear Strength - Excellent

GSS Dry State - 1458 N Avg, 1188 N min Individual

GSS Wet State -1080 N Avg, 864 N Min Individual

Mechanical Data - Excellent

Density - Above 750 kg/m3

Tensile Strength - Excellent

Parallel to grain direction - Above 50 N/mm2

Perpendicular to grain direction - Above 38 N/mm2

Sum in both direction - 88 N/mm2

Stands more than 72 hours of continuous boiling

CONFORMS to IS 5509:2000

Bonding Properties is as per IS 710

Unique Features

Boiling Water proof

Resistant to ignition, spread and permeability of fire: unlike common ply, Uniply Fire Protect creates a barrier against fire, due to its slower fire penetrating rate

Treated with fire resistant chemicals at veneering stage.

Equipped against the risk of unchecked spread of fire

Fungi, insect and borer resistant

Antifungal Treated

Complies with Calibrated

Stringent American Standard ASTM E84 - 16 complies
